15" TWO-WAY MULTIPURPOSE SELF-POWERED SOUND REINFORCEMENT
The new EON600 is a true step forward in technology developed specifically to deliver the best sound possible regardless of its application, which provides more than just another great JBL sound system. JBL engineers purposely designed and built the EON600 from the ground up featuring JBLs advanced waveguide technology which completely rethinks how truly good an affordable self-contained, portable PA system can be. JBL designed and manufactured transducers, and convenient, wireless remote control of its onboard DSP EQ parameters via Bluetooth. This total redesign of the EON platform leverages the latest technologies in cabinet materials, acoustic science, transducer design and user friendliness that delivers the extraordinary quality of a high-end studio monitor in a fully professional, highly flexible, easy to use, portable system for todays working musicians and sound providers.
Enclosure designs have been optimized for ideal acoustic resonance taking advantage of injection molding techniques and mechanical shaping of the enclosures.
JBL Waveguide Technology
JBL EON615 PA LOUDSPEAKER SPECIFICATIONS
System Type Self powered 15", two-way, bass-reflex
Max SPL Output 127 dB
Freq. Range (-10 dB) 39 Hz - 20 kHz
Freq. Response (±3 dB) 50 Hz - 20 kHz
Coverage Pattern 90° x 60°
Amplifier Design Class D
Power Rating 1000W Peak (700W LF + 300W HF), 500W Continuous (350W LF + 150W HF)
Dimensions (H x W x D)
707 x 439 x 365 (mm)
27.8 x 17.3 x 14.4 (in)
Net Weight 17.69 kg (39 lbs)
